| Inquiry | Bearing NO. | Shape Dimension(mm) | Basic Load Rating(N) | Weight | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| d(mm) | d(inch) | D(mm) | D(inch) | B(mm) | B(inch) | r min(mm) | r min(inch) | Dynamic( Cr) | Static( Cor) | (kg) | ||
| S6000 | 10 | 0.3937 | 26 | 1.0236 | 8 | 0.3150 | 0.3 | 0.0118 | 4160 | 1780 | 0.0190 | |
| S6001 | 12 | 0.4724 | 28 | 1.1024 | 8 | 0.3150 | 0.3 | 0.0118 | 5110 | 2380 | 0.0220 | |
| S6002 | 15 | 0.5906 | 32 | 1.2598 | 9 | 0.3543 | 0.3 | 0.0118 | 5590 | 2840 | 0.0300 | |
| S6003 | 17 | 0.6693 | 35 | 1.3780 | 10 | 0.3937 | 0.3 | 0.0118 | 6000 | 3250 | 0.0390 | |
| S6004 | 20 | 0.7874 | 42 | 1.6535 | 12 | 0.4724 | 0.6 | 0.0236 | 9390 | 5020 | 0.0690 | |
| S6005 | 25 | 0.9843 | 47 | 1.8504 | 12 | 0.4724 | 0.6 | 0.0236 | 10060 | 5860 | 0.0800 | |
| S6006 | 30 | 1.1811 | 55 | 2.1654 | 13 | 0.5118 | 1 | 0.0394 | 11900 | 7460 | 0.1160 | |
| S6007 | 35 | 1.3780 | 62 | 2.4409 | 14 | 0.5512 | 1 | 0.0394 | 16210 | 10420 | 0.1550 | |
| S6008 | 40 | 1.5748 | 68 | 2.6772 | 15 | 0.5906 | 1 | 0.0394 | 17030 | 11700 | 0.1920 | |
| S6009 | 45 | 1.7717 | 75 | 2.9528 | 16 | 0.6299 | 1 | 0.0394 | 21080 | 14780 | 0.2450 | |
| S6010 | 50 | 1.9685 | 80 | 3.1496 | 16 | 0.6299 | 1 | 0.0394 | 22000 | 16260 | 0.2610 | |
Providing a variety of high-performance bearing products and customized services. No matter where you are, you will get the best service to go along with the best bearings.
